SMBPM-8 DOD UV Print with LF&HF&UHF Smart Card Data Perso Machine

SMBPM-8 DOD UV Print with LF&HF&UHF Smart Card Data Perso Machine is professional machine for Banking card / VISA Card / Master Card / Driver Licence Card / ID card personalization.

1. First Feeder: load CR80 cards for contactless LF & HF & UHF smart card personalization, contact chip SIM card & Banking card personalization, magnetic banking card encoding.

2. Double Card Detection: if double card from feeder, automatic stop and alarm.

3. Contactless smart card data personalization modules: read UID from module, load data from database or fixed data by our software setting, write data for 0-15sectors and different blocks and change A key and B key up 7000pcs card per hour.

4. Adjustable Second Feeder: Load CR80 cards if only printing by second feeder, save time. Adjust the feeding module, load special size cards if only printing, maximum A4 sheet.

5. Plasma Treatment: Make the card surface easier to adhere to UV ink.

6. DOD UV Multi-Color / Single Color Printing: Print one dimensional code, two-dimension barcode, personalization numbers, drug administration codes, anti-counterfeiting code, security code, database, serial / swift numbers, various patterns and any other languages. Load text & photo data as database, printing speed up to 13000pcs card per hour.

7. LED UV Dryer: Dry the UV ink after printing.

8. OCR(Optical Character Recognition) Verification: Verifies printed numbers, text, bar-code, QR-code and other codes and data from the database and layout.

9. Rejection module: Identification system of  the defect products on each stage of equipment operation (data of the contactless &  printing personal data on the card) and dispatch to the  rejection module for the cards.

10. Final conveyor: Collect finished good cards.

11. Controller: Management and control of encoding, printing, verification, rejection and product transfer on the  transport system.

12. Monitor: control panel

13. Software: English.
