We're 19 years Know-How on card lamination machinery, this new offer SMCLM-7A Full Automatic Rotary RFID Contactless Smart Card Laminator System focuses on laminating various plastic cards, inlays sheets and contactless cards with revolutionary innovation!
The system specially designed for mass production of big sheet likes 6*8/6*9/7*8 with amazing and innovative design.
All loading and unloading jobs will be operated automatically by a smart rotary system. This card laminator is able to synchronize the sheets feeding and discharging.
The unique tech of from low to stronger steps pressure will reduce the chip loss rate during RFID card/ inlay pre-lamination, keep the pressure close between upper openings and bottom openings, ensure the sheets lamination in high quality.
With 2 groups aluminum-alloy press platens, hydraulic-pump frequency conversion pressing, advanced PLC and temperature control modules, the machine can work well with 4 press cylinders in multistage laminating for excellent results.
The precise pressure control, well-distributed heating, less circle time & higher capacity, energy saving & environment friendly, all are the features of such amazing system.
The tailor-made service is also available to you!
Lamination Materials: paper and plastic materials like Teslin, PVC, PET, PETG, ABS, Polycarbonate(PC) and so on .
Usage: bank/credit card, contact IC card, contactless smart card, RFID label, paper card, magnetic card, pre-laminated inlay.
SMCLM-7A Full Automatic Rotary RFID Contactless Smart Card Laminator
Advanced Heating System
The aluminum-alloy press platen leads the excellent even heating transit, controlled by PLC for high precision temperature and pressure transmitting frequency converter.
15 heating rods in each press platen. Advanced sensor & PLC controls each press layer's temperature precisely. The heating temperature is up to 220C with tolerance of 1C.
Quick and even heat transferring will shorten the cycle time. High efficiency, energy saving and environment friendly are also advantages.
Advanced Pressure Control System
Pressure range 0-16MPa, Controlling precision 0.1 MPa, which achieved by advanced pressure sensor and PLC control system.
The top-level hydraulic system will ensure the reliable & stable working.
High Pressure Accuracy and Even Temperature
In heating & cooling press stations, there are 4 hydraulic cylinders working together and pressures controlled by 2 motor and hydraulic pumps. 19 years practices authenticated that precised temperature control comes from simple temperature setting!
Amazing and Innovative Design
Thanks for 20 years experience on card lamination system, as the biggest market-share players from China, we released such simple and effective rotary lamination system with auto loading and unloading system.
Leading and Outstanding Tech
The advanced pressure and temperature control system, the shortest operation route including material loading or unloading, transfer loading system,also the most effective rotary technologies in world market.
The compact size and floor space allows you easily machine location and installation.
Unique Design and Tech For Slight-Press Starting
Will increase the production yield and make final card lamination quality in top level.
Easy Operation and Maintenance
All system controlled by PLC and operated by touch screen. All parameters set on human screen. Easy operation and maintenance are the highlights. 10 groups laminating parameters stored in system. Get easy operation for repeat order.
Durable 7days*24hours/day Industrial Concept
19 years experiences and numerous references will bring you the proven system and reliable services. The machine is suitable for the 7days*24hours/day mass production.
Modular Design and Flexible Tailor-Made Service
The innovative modular design and rotary loading and transportation system makes the simple structure. Any layout including 6*8 or double 3*8, 6*9 and 7*8. Custom made service for any global user!
Model | SMCLM-7A Full Automatic Rotary RFID Contactless Smart Card Laminator |
Platen Press Area | 700mm*550mm (our standard model) , Other dimension on your request |
Max. Material Sheet Size | 680mm*550mm, please state your laminate sheet size when ordering |
Support Sheet Layout | 3*7, 3*8, 3*9 or double packages for 3*7, 3*8, 3*9
4*7, 4*8, 4*9, 6*7, 6*8 , 6*9, 7*8 etc. |
Lamination Station | 1 tower for heating lamination press, 1 tower for cooling lamination press |
Heating Method | Electric Heating Rod for maximum 400C
normally 95-180C if you use new card materials or recycle card materials |
Cooling Method | outer chiller / Cooling Machine, automatic water cyclic utilization |
Opening/Daylight | regular 7 hot and 7 cold, maximum 9 hot and 9 cold, on customized demand |
Opening Space Distance | 50mm, suggest to put 10-15 packages laminate sheets in each opening |
Cycle Time | 15-18minutes Hydraulic Pressure
0-16MPa and maximum 70Tons, 8units hydraulic cylinders |
Control Method | PLC and Touch Screen |
10 Parameter Records | setting could be stored in System, easy to repeat order and production management |
Power Supply | 3 phase and 5 lines, AC 380V, 50-60Hz |
Consumption | 60 KW (for regular model of 7x8 layout), cost 12KW per hour |
Net Weight | 7000 KGS |
Machine Dimension | 4500mm(L) * 3800mm (W) * 2010mm (H) |
Advised space for operation and maintenance | 6500mm (L) * 6000mm (W) * 3000mm (H) |
Leading Time | 60 working days (10-12weeks) |
FAT/Training Time | 2-3 days in supplier assembly factory |
Operator | we have two operate positions for 2 operators, save time, more faster |
