SMCLM-2B smart card laminating machine is used to laminate plastic sheets, make plastic card, bookmark, photographic image. special used to laminate contactless smart card, laminate contactless inlay, laminate magnetic card.
SMCLM-2B RFID Contactless Smart Card Laminating Machine
| Lamination Area | usual 220*310mm or any other size in your order |
| Lamination Opening | 1 opening for heating, 1 opening for cooling |
| Pressure Method | oil hydraulic pressure system |
| Control Method | MicroComputer |
| Pressure Range | 0-16MPa ± 0.1MPa 0-18Tons |
| Temperature Range | room temperature to 400 centigrade |
| Heating Method | electric power (imported heating elements) 2units temperature module |
| Cooling Method | automatic chiller inside machine ( environmental protection ) |
| Working Efficiency | 100-200pcs A4 sheets per hour |
| Input Voltage | 380V or 220V 50/60Hz |
| Power | 4.5KW |
| Power consumption | 0.5-1KW per hour |
| Dimension | 880mm*530mm*1370mm |
| Net/Gross Weight | 350KGS/380KGS |
