SMNCM-100 All-In-One Contactless Smart Card Inlay Machine is developed on our separate smart card inaly machines.
We're professional manufacture for card making machines, we have different capacity contactless smart card making machines for inlay.
We can offer 1-16 heads machines by different customers request. As we are many years specialized in smart card making machinery and consider for some high-end expensive and of high quality customers request, we cost 4 years to create this all-in-one contactless smart card inlay machine by our research and development team.
During 15months testing, we're sure our SMNCM-100 All-In-One Contactless Smart Card Inlay Machine will be widly used for many card making factories. It's stable and save time and save labour and save power and increase production capacity.
Operation Steps:
Step 1: take sheet on machine for two holes punch.
Step 2: fix sheet on machine, there are 2 pins on each working tabel.
Step 3: press start switch, machine automatic move sheets for antenna embedding.
Step 4: at the same time as Step 3, the chip placing heads automatic apply glue for chips.
Step 5: machine automatic move sheets to next stations, automatic place chips on sheets. each working tabel has 2units chip placing system.
Step 6: machine automatic move sheets to next stations, automatic chip embedding.
Step 7: machine automatic move sheets to origin stations, testing.
Step 8: take away the finished sheets, put new ones.
Machine has monitor for each working stations condition.
If 8heads machine, we can adjust machine for less heads working, so machine can work for different formats.
Model | SMNCM-100 All-In-One Contactless Smart Card Inlay Machine |
Power | 5-8KW depends how many heads working
|
Voltage | 220V 50/60Hz |
Capacity | if 3heads + 3heads working, 2400 cards/h |
| if 5heads + 5heads working, 4100 cards/h |
| if 8heads + 8heads working, 6500 cards/h |
Control | PLC+Touch Screen+Operation Monitor |
Machine Size | 3000mm*1200mm*1700mm |
Net Weight | 2600KGS |
Operator | 1 operator for 2sets SMNCM-100 All-In-One Contactless Smart Card Inlay Machine
|
